Specifications
The complete technical record.
Every published figure for the MUOV bike, searchable and grouped by system.
37 specifications
Performance
- Power accuracy
- ±0.5%
- Maximum power
- 2,500 W
- Maximum cadence
- 165 rpm
- Maximum simulated gradient
- 25%
- ERG mode
- Available
- Data refresh rate
- 30 Hz
- Q factor
- 150 mm
- Drivetrain
- Belt drive
- Drive unit
- Low inertia for improved pedal responsiveness
Movement & steering
- Steering
- Patented combined steering and leaning
- Maximum lean angle
- Up to 12°
- Braking
- Fully enabled braking
Rider fit & frame
- Rider height range
- 152–200 cm (5'0"–6'7")
- Frame sizes
- 3 — Small, Medium, Large
- Frame swap
- Hot swappable in under 30 seconds
- Crank lengths
- 150, 155, 160, 165, 170, 172.5, 175 mm
- Stem lengths
- 70–120 mm
- Handlebar widths
- 380–420 mm
- Saddle
- Interchangeable — customer specified available
- Pedals
- Interchangeable — rider choice
- Maximum rider weight
- 110 kg
Controls & shifting
- Shifters
- Bespoke MUOV ergonomic shifters
- Electronic shifting
- SRAM or Shimano style, programmable in the MUOV app
- Controller buttons
- Zwift-compatible
Connectivity
- Protocols
- Bluetooth BLE FTMS, Wi-Fi
- Bluetooth connections
- 4 concurrent; master connection controls resistance
- Bluetooth range
- Greater than 7 m
- USB ports
- 2 × USB-C
Physical
- Bike weight
- 41.8 kg
- Base weight
- 35.9 kg
- Carbon fibre frameset
- 5.9 kg
- Footprint dimensions
- 118 cm × 76 cm
- Shipping dimensions
- Upon request
Manufacture
- Designed & engineered
- United Kingdom
- Place of manufacture
- United Kingdom
- Build
- Built to order — delivery approximately 4–6 weeks
- Warranty
- 3 years / 50,000 km (whichever comes first)
